Ampere Hour Meter

We are offering IM 2500 Series Ampere Hour Meters are instruments for Battery Monitoring and Electroplating Applications. Numerous options and features make it highly versatile and suitable for various applications. Use of timer control in such applications is highly inaccurate. AH meter replaces the timer giving precise control and many more facilities.
Battery charge / discharge monitoring
Rectifier on / off control
Rectifier control while plating of metals like Gold / Silver / Nickel etc.
Doser control for adding additives and brightener.

Also available as Ampere min / amp min / Ampere minute meters OR ampere sec / amp sec / ampere second meter, etc

Features

* Microcontroller based highly versatile and reliable digital circuitry.
* Dust proof membrane keyboard for programming.
* Ampere Hour / Ampere Min or Ampere Min / Ampere Seconds selection from keyboard.
* Four digit display for current count.
* One preset count with relay output at preset count.
* Shunt value programmable from keyboard.
* Floating decimal point, automatically selected depending on shunt value. One decimal resolution for    shunt values below 25A.
* Battery back up to retain count in case of power fail.
* External Reset input to reset count.
* Size 96 x 96 x 150 mm.

Models Available are,

IM2501: 4 digits Ampere Hour Meter
IM2502: IM2501 with 6 digit totaliser
IM2503: IM2502 with doser control outputs for electroplating
IM2505: 6 digit charge discharge Ampere Hour meter
IM2506: 6 digit AH Meter
IM2507: 4 digit charge discharge display AH Meter

Specifications

• Input : 75 mV / 5 V

• Resolution : 0.1 AH for Shunts < 25 A

• 1 AH for Shunts > 25 A

• Current Display (Optional) : Floating Decimal

• Supply : 230 V 50 Hz AC / 110 V AC / 24 V DC / 12 V DC

• Size : 96x96 mm depth 150 mm

Models

• IM 2501 Ampere Hour Meter without Totaliser

• IM 2502 Ampere Hour Meter with Totaliser

• IM 2503 Ampere Hour Meter with Totaliser and Doser Outputs.

• TE2504 Ready to use Module with Shunt, relay, buzzer / lamp indication etc. packed in a
   stand alone cabinet. Ideal for Electroplaters.

• Im2505 Ampere Hour Meter with charge / discharge counts.

Options

• Early warning relay output.

• RS232 / RS485 output for computer interface.

• Printer output.

• Ampere Display

• Programming with a Remote Control.

Ordering Details

• IM2501 : 4 digit AH Meter

• IM2502 : 4 + 6 digit AH Meter

• IM2503 : 4 + 6 digit AH Meter + doser

• TE2504 : Module with IM2503

• IM2505 : 6 digit AH Meter with Charge Discharge

• IM2506 : 6 digit AH Meter

Suffix :

• C : Current display

• S : Serial RS232 Modbus Interface

• M : Serial RS485 Modbus Interface

• E : Early Warning Relay

• X : Amp Sec / Amp Min

Display : 4 / 6 digit Single / Dual
Settings : Membrane Keyboard
Ranges : Various from 0.01 sec to 9999 hrs.
Resolution : Minimum 1 mSec possible
Count mode : Up / Down
Output : Upto 4 Relays.
               More relays possible externally.
Battery Backup : Optional
Other Options : RS232 / Modbus Connectivity
/ Real Time operation

• On/Off Timers l Cyclic Timers l On / Off Delay Timers
• One Shot Timers l Sequential Timers
• Timers with Totalisers l Timers with Counter l Timers with Real Time

Display : 4 / 6 digit Single / Dual
Settings : Membrane Keyboard
Count mode : Up / Down
Input : Proximity / Potential free Contacts Optical Encoder / Quaderature
Output : Upto 3 Relays. More relays possible.
Battery Backup : Optional
Prescaling : Optional. Multiplying / dividing constant programmable
Reset : External Manual / Auto / Programmable timeOther Options: External Start / Stop / RS232 /Modbus Connectivity

• Preset Counter
• Sequential Counter
• Counter with Totaliser
• Batch Counter
• Vending Machine Timer / Counters
• Up Down Counters / Prescaling Counters

In a process control environment, many events like Solenoid operations, relay operations, Alarms etc. occur and it is important to log the sequence of these events. Event logger accepts digital / ac inputs and keeps a track of such events.

Features
• Microcontroller based circuitary
• Potential free contact inputs
• Number of channels from 1 to 64
• Data logging at periodic interval as well as on
   change of input status
• PC interface
• On line data printing
• Optional counter facility
• Optional SMS facility on an event
