..................................About Us



Machine For Fasteners & Hardware Industries, Packaging Machinery, Autoweighers & Conveyors


The Essence of Our Company : Quality

We are leaders in the packaging machine industry manufacturing all kinds of packaging machines for about 3 decades.  We have a whole range of baggers, wrappers, and automated feed systems that are designed with speed, efficiency & economy in the mind, not  only to meet the needs of your business but also give it a subsequent boost.
Engineered for consistent quality, quick and simple product changeovers, flexibility and low maintenance, our packaging machines are custom made to meet your specifications.  We have built our reputation by providing consistently good quality packaging machines,   prompt deliveries, efficient customer service, and total customer satisfaction.




A Future Eye for Excellence : Vision


We see ourselves as solution providers, we identify with the objectives of our customers.  Their vision becomes our vision and vice versa.We believe the best solution is tailored according to our customers needs and fulfils precisely the specified requirements.  We   believe in keeping pace with technology, We believe in keeping pace with tomorrow.




Corporate Policy towards quality : Teamwork

At the heart of our company lies a commitment to quality.  Behind every successful organization is a team of committed people striving   their best to keep up its name.  So is the case with us.  Be it sales, customer service, technical or finance we have a dedicated team   that keeps the enthusiasm flowing so that our customers are satisfied.

  ..................................Product

BCG-100

 ( BELT CONVEYOR GROSS )

Type of Machine: Semi Automatic, predetermined Gross Weigher with double speed belt conveyer to feed the material.
Suitability : For granular and free flowing coarse powder,
small and big lumps, irregular non-sticky materials, such as cattle/poultry feeds, oil cakes, chemicals in flakes, fertilizers, oil extractions, spray dried detergents, etc.
Range : 25 to 50 KGs & 50 to 100 KGs.
Accuracy : + 0.25% to + 0.5%
Principle : Gross Weigher
Output : 10 to 12M.T. per hour*
Contact Parts : MS or SS.304 or SS 316 (MS structure)
Power : 2 HP, Single Phase, 230 V AC, 50 Hz**
Dimensions : L 1450 x W 1150 x H 1350 mm (approx.)***
BELT CONVEYOR GROSS

  ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SCN(P)-100 SCREW CONVEYOR NET ( PNEUMATIC )
Type of Machine: Semi Automatic, predetermined Nett Weigher with double speed motorized screw conveyor to feed the material with pneumatically operated functions.
 Suitability :  Free flowing powders, poultry feed, chemicals, gums, cement, bleaching powder, coarse and fine powders of 350mesh can also be bagged if rotary air lock is provided between the storage bin and auxillary hopper.
Range : 25 to 50 KGs & 50 to 100 KGs.
Accuracy : + 0.25% to + 0.5%
Principle : Net Weigher
Output : 8 to 12 M.T. per hour *
Contact Parts : MS or SS.304 or SS 316 (MS structure)
Power : 2 HP, Single Phase, 230 V AC, 50 Hz**
Dimensions : L 1250 x W 1200 x H 2500 mm (approx.)
SCREW CONVEYOR NET ( PNEUMATIC )
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
ICCS INVENTORY COMPUTING CRANE SCALE
Type of Machine: This is a portable Electronics Weighing Crane Scale with 5000 memory and 10 to 15 metres cable length between Hook and Display. This machine can be operated on Mains as well as on Battery with Printer. It is also available on remote based control.
Suitability : It is a compact measuring devise for the weighing of loads in hoisting gear.
Range : 1 MT / 2 to 3 MT / 5 MT / 10 MT / 20 MT
Accuracy : 200 gms. division / 500 gms. division / 1 kg. division respectively, depending upon the range.
Principle : Net weigher
Power : 2 H.P, 440VAC, 3 Phase, 50 cycles **
Dimensions : Depends on the selected range***
INVENTORY COMPUTING CRANE SCALE
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SVFA-50/500 SCREW VOLUMETRIC FEEDER AUGER
Type of Machine: Auger filler are volumetric powder filling machines, which are most suitable for filling free flowing and semi-free flowing powders into any type of container. The different ranges can be covered with different sets of Auger & Funnel
Suitability : Auger fillers are suitable for free flowing powders like chilly, turmeric, spices, masala, soft drink concentrate, food colours and pharmaceutical powders
Range : 50 grams to 500 grams (with interchangeable augers).
Accuracy :

a) 50 grams + 1 gram to + 1.5 grams b) 100 grams + 1 gram to + 2 grams c) 200 grams + 4 grams to + 5 grams d) 500 grams + 4 grams to + 5 grams

Hopper Capacity : 1.2 cu. ft.
Output : 900 / 2500 fills per hour depending on the filling quantity.
Size : 30" X 30" X 54"
Power : 1HP, Single Phase / 3 Phase, 440 V, 50 Hz.
Dimensions : L 762 x W 762 x H 1372 mm (approx.)
SCREW VOLUMETRIC FEEDER AUGER

  ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
  ..................................Contact



Registered Office :
69A/21, Brindavan Society, Thane - 400 601, Maharashtra, INDIA
* TeleFax : 91 - 022 - 25430225 * Mobile : 9819292753

Sales / Marketing Office :
A-202, Prakriti, K K Woolen Mill Compound, Raghunath Nagar,
Wagle Est.,Thane - 400604, Maharashtra, INDIA   * Tel.: 91 - 022 - 25804345
* Telefax : 91 - 022 - 2583 0695

Works :
B35-3, M.I.D.C. Addl. Ambernath, Anand Nagar,
Ambernath - 421 506 Dist. Thane, Maharashtra, INDIA
* Tel. : 91 - 0251 - 2621290

* Email
:
* Website
:
www.mazdaintl.com
