Precision Weighing Systems is one of the leading suppliers of a wide array of weighing equipment including Conversion Kits, Table Top & Platform Scales, Milk Weighing Scales, Heavy Duty Platform Scales, Bagging & Batching Systems, Tank Weighing Systems and more. Our diverse range of measurement applications are devised to complement the rapid advancement of technology in science, medicine and other fields. Combining years of experience and technical expertise, we have been able to provide accurate sensing technology to satisfy the varying demands of our customers.

The complete manufacturing process is carried out by our sister concern, Kunal Enterprises. It has a world-class manufacturing unit equipped with the latest machinery for manufacturing precision weighing system with great accuracy. We adopt a stringent quality control throughout the manufacturing process in order to ensure international quality of product. Our unflinching effort to quality has honored us with the prestigious certification of ISO 9001:2000. With our strong belief in maintaining long-lasting relationship with the customers, we strive to provide our customers products and services second to non in the industry
Products

Weighing Systems
We supply a wide range of precision weighing system that are user friendly and known for accurate measurements. These products incorporate latest technology and are designed to meet the most demanding needs of our customers. The broad spectrum of products supplied by us include the following conversion kits, platform scales, milk weighing scales, bagging systems, tank weighing systems, weight indicators, electronic weigh bridges and axle weigh bridges.

Electronic Weigh Bridges

We manufacture pit-less or pit type weighbridges as per space availability at site. While pit-less model enjoys the benefits of less civil work, easy maintenance & no water logging problems, pit type model requires less space & has the benefit of free vehicle movement.
Electronic Weigh Bridges

• Capacity available upto 150 ton
• Load cells are hermetically sealed to NEMA 6 / IP68 standards
• Micro controller based circuitry for fast operation
• Self diagnosis mode
• Automatic Calibration Check
• Password Security
• IBM key board interface
• RS 232C / RS 485 / RS 422 port for computer interface
Axle Weigh Bridges

In axle weighbridges, there is a small platform (2 m x 3 m) on which axles of the vehicle are weighed one by one. Weight of all the axles is then added to give total weight of the vehicle.

This weighbridge finds application in stone crushers or to weigh less costly materials where economy rather than accuracy is of prime importance.

This weighbridge is an accurate weighing system which can weigh any type of vehicle regardless of its length or the no. of axles it has.

When a vehicle moves across the platform at slow speed & front axle stops on it for a moment, the electronics waits for the axle weight to become steady and then catches this weight into memory. It has a light, which goes off when the weight has been captured so that the driver knows when to move to the next axle. After that, each axle is weighted and its weight is stored in memory to give the total weight of the vehicle.
Axle Weigh Bridges
Foundation Less Weighbridges

Foundationless weighbridges are boon to industries like mining, quarries & construction which need to shift the weighbridge from site to site. Conventional weighbridges have heavy rigid platforms and require costly & time-consuming civil foundation. This makes shifting of the weighbridge very expensive as trailers/open truck is required to transport it and again civil foundation has to be built at the new site. Also, time taken & labor involved for dismantling and re-commissioning is enormous and hence adds to the cost of shifting tremendously.

Our unique design of foundationless weighbridge eliminates all the above disadvantages of conventional weighbridge and enables quick shifting at a very low cost. Its modular design makes it easy to transport & civil foundation required is very minimal. The platform sits on a removable frame that, when bolted together, forms a solid base, complete with end walls. No ramps are required.

Just fill concrete out side the end walls & forget. Ramp height < 300 mm. Concrete footings are required to support each load bearing point of the base frame.

Foundation Less Weighbridges
Weighing Pads


















Mild steel construction

Designed for rough & tough industrial applications

Each pad contains load cells which can be replaced individually if required

Can be placed on a leveled tar or concrete road

A set of four pads can be used as an economical alternative to regularweighbridge.

Ramp height- 100-180 mm depending on capacity & size

Portable enough. Can be shifted easily

Fully calibrated and ready to use. Installation time takes less than one hour.
Weighing Pads
Ultra slim weigh pad

An ultra slim Weigh pad system is an ideal portable weighing system. Each pad is fed into a different channel, allowing individual calibration for each pad.A portable data case including rechargeable battery, dot matrix roll printer,and LCD digital readout can be supplied for installations which require frequent shifting.The system is factory calibrated and ready to use when you get it. It can easily be setup by a single individual in minutes and is very easy to use and transport.

Available in capacities up to 20 tons per pad

Available in capacities up to 20 tons per pad

Machined from light weight high strength aluminum alloy

Weight: 23 kg including ramps, 19 kg without ramps

20 independent micro loadcells in each pad

Static Accuracy: 0.25% full scale or better

Dynamic Accuracy: + / - 1% of full scale with leveling track

Graduation- 10 kg

Ground level Requirement- concrete or asphalt surface, level within 1/8" over entire supported area

Temperature range -20°C to 60°C

Optional leveling track of High density plastic / rubber compound


Ultra slim weigh pad
